Workflow Builder

The Workflow Builder turns a business rule into automation. A workflow watches one entity type (invoices, purchase orders, leave requests, deals, and so on), waits for a trigger event, checks a set of conditions, and then runs actions — which can include routing the record through an approval chain.

Workflow Management — Builder canvas showing trigger, conditions and approval chain

Before you begin

Confirm the relevant feature toggles are enabled in Workflow → Settings (e.g. require_po_approval, multi_level_approval, parallel_approval).
Decide whether the “does this need approval” decision belongs in a Policy (a numeric threshold) rather than in the workflow itself. Keep workflows focused on who and what.

Create a workflow

Step 1 — Choose the entity

Go to Workflow → Workflows and click New Workflow. Pick the entity type the workflow applies to (for example Purchase Order, Invoice, Leave Request, Deal). Every workflow is scoped to exactly one entity — its conditions and fields come from that entity.

Step 2 — Pick the trigger

Select the event that starts the workflow:

Trigger	Fires when…	Typical use
On create	A new record is saved	Route every new PO for approval
On update	Any field on the record changes	Re-check when an invoice amount is edited
On status change	The record’s status/state moves (e.g. draft → submitted)	Start approval only after the user submits

Prefer On status change for approval flows — it avoids firing while the user is still drafting the record.

Step 3 — Add conditions (JSONLogic)

Add one or more conditions that must all be true for the workflow to act. Conditions are evaluated with JSONLogic against the record’s fields. Use the visual condition builder, or edit the JSONLogic directly.

Example — only for large, non-VN purchase orders:

{ "and": [
  { ">": [ { "var": "totalAmount" }, 50000000 ] },
  { "!=": [ { "var": "supplierCountry" }, "VN" ] }
] }

See the operators reference below.

Step 4 — Define actions

Choose what happens when the trigger fires and the conditions pass:

Action	What it does
Create approval	Starts an approval chain (see Step 5)
Auto-submit	Moves the record into the submitted/pending state automatically
Auto-execute	Runs the record’s next lifecycle step automatically (e.g. post, confirm)
Assign	Assigns the record to a user or role
Notify	Sends an in-app / email notification to users or roles
Set field	Writes a value to a field on the record

A workflow can run several actions in one pass — e.g. set a field, notify the requester, and create an approval.

Step 5 — Build the approval chain

If you added Create approval, define its levels. Each level can be serial or parallel:

Serial (A → B → C): level 2 only starts after level 1 approves. Use for escalation ladders (Manager → Finance → CFO).
Parallel (A AND B): all approvers at the level must approve before the chain advances. Use for dual control or cross-department sign-off.

You can mix them: run levels 1 and 2 in parallel, then require a final serial level 3.

⚠️

Multi-level chains require the multi_level_approval toggle; parallel levels require parallel_approval. Without them, only a single-approver step is honoured.

Workflow Management — configuring serial and parallel approval levels

Step 6 — Test

Use Test (or run a sample record from the source module) to confirm the workflow triggers, its conditions match, and the chain routes to the intended approvers — without affecting production records.

Step 7 — Activate

Toggle the workflow Active. It now runs on every matching event. Inactive workflows are saved but never fire.

Conditions operators reference

JSONLogic operators available in the condition builder:

Operator	Meaning	Example
`==` / `===`	Equals	status equals `submitted`
`!=` / `!==`	Not equals	department not `IT`
`>` `>=` `<` `<=`	Numeric comparison	amount `>` 50,000,000
`in`	Value is in a list	category `in` `["capex","opex"]`
`and`	All sub-conditions true	amount high AND new supplier
`or`	Any sub-condition true	overdue OR flagged
`!`	Negation	NOT approved
`var`	Reference a record field	`{ "var": "totalAmount" }`

Field names in var are the entity’s stored field keys (usually camelCase, e.g. totalAmount, discountPercent, supplierId). The visual builder lists valid fields for the chosen entity so you don’t have to guess.

Trigger types reference

Trigger	Scope	Notes
On create	New records only	Fires once, at insert
On update	Field changes	Can fire repeatedly; scope with conditions to avoid loops
On status change	State transitions	Best for approval kick-off; pairs with an entity’s lifecycle

Actions reference

Action	Blocking?	Common pairing
Create approval	Yes — holds the record until decided	Notify approvers
Auto-submit	No	On create trigger
Auto-execute	No	After final approval
Assign	No	Notify assignee
Notify	No	Any step
Set field	No	Stamp risk level / route code

Troubleshooting

Symptom	Likely cause	Fix
Workflow never fires	Wrong trigger, or workflow inactive	Confirm trigger matches the real event; set Active
Fires but doesn’t route to approver	Conditions never match	Test conditions against a real record’s field values
Only one approver acts despite multi-level	`multi_level_approval` off	Enable in Workflow → Settings
Parallel level acts serially	`parallel_approval` off	Enable the toggle
Loops on every save	Broad On update trigger	Add a condition that stops re-firing (e.g. status guard)
Approver on leave, chain stalls	No delegation	Create a Delegation rule

FAQ

Q: Can one workflow cover several entities? A: No. Each workflow is scoped to one entity. Create separate workflows (or start from a template) per entity.

Q: Where do the field names in conditions come from? A: They are the entity’s stored fields. The visual builder lists them for the entity you chose in Step 1.

Q: How do I stop an approval flow I no longer want? A: Toggle the workflow Inactive. In-flight approvals continue; no new ones start.
